arameters
Function
Description
CPU
RK3399Pro,Big.Little architecture: Dual Cortex-A72 + Quad Cortex-A53, 64-bit CPU,Frequency is up to 1.8GHz
GPU
Mali-T860MP4 GPU, OpenGL ES1.1/2.0/3.0/3.1, OpenVG1.1, OpenCL, DX11
NPU
NPU up to 3.0TOPS，Support 8-bit/16-bit Inference，Support TensorFlow/Caffe Model
DDR
LPDDR3, 3GB/6GB (Optional)
eMMC
eMMC 5.1, 8GB/16GB/32GB/64GB/128GB(Optional)
PMU
RK809,Support a variety of power supply
Camera Interface
Two ISP built-in
Dual MIPI-CSI 4 Lane of 1.5 Gbps/Lane
ITU-R BT 601/656 compliant
Maximum input resolution of one ISP is 14M pixels
Display Interface
Two VOP embedded
Dual MIPI-DSI 4 Lane of 1.5 Gbps/Lane up to 2560x1600@60fps
eDP1.3 4 Lane of 2.7/1.62 Gbps/lane
DP1.2 4 Lane with HDCP2.2 up to 4kx2k at 60Hz resolution
HDMI2.0 3 Lane with HDCP2.2
USB Interface
OTG*1，HOST*2，TYPE-C*2
TYPE-C Interface
Dual Type-C PHY with Type-C V1.1 and USB PD2.0
Attach/detach detection and signaling as DFP, UFP and DRP
Support USB3.0 Type-C and DisplayPort 1.2 Alt Mode
Up to 5Gbps data rate for USB3.0
Up to 5.4Gbps (HBR2) data rate for DP1.2
Audio Interface
Three I2S/PCM built-in
SPDIF supported
Audio resolution from 16bits to 32bits
Sample rate up to 192KHz
Provides master and slave work mode, software configurable
Support 3 I2S formats (normal, left-justified, right-justified)
Support 4 PCM formats (early, late1, late2, late3)
Support two 16-bit audio data store together in one 32-bit wide location
Support 16, 20, 24 bits audio data transfer in linear PCM mode
Connectivity
Compatible with SDIO 3.0 protocol
GMAC 10/100/1000M Ethernet Controller
Six on-chip SPI controllers
Five on-chip UART controllers inside
Nine on-chip I2C controllers
Five groups of GPIO (GPIO0~GPIO4), totally have 122 GPIOs
One PCIe port compatible with PCI Express V2.1 and dual operation mode（RC and EP）
Six-channel single-ended 10-bit SAR-ADC up to 1MS/s sampling rate
OS
Android / ubuntu / Buildroot
PCB interface
B2B，280 Pin
PCB size
L* W* H(mm) : 75 * 55 *7.8（PCB 1.2mm）
