Product Features:
Intel LGA1700 socket, compatible with 12th to 14th generation Intel processors. Featuring the latest Intel 7nm hybrid architecture CPU, it offers powerful computing performance and excellent power consumption performance, which can adapt to application scenarios with different requirements.
Equipped with 4 Intel i226 chips, it provides up to 2.5Gbps network bandwidth. It can meet the needs of high-speed data transfer and is backward compatible with 10/100/1000Mbps.
Supports the latest DDR5 SO-DIMM, dual-channel supports up to 96GB memory, provides higher bandwidth and lower latency, and improves the overall system performance.
Offers 2 M.2 SSD and 8 SATA storage slots, providing high-speed, high-capacity storage solutions to meet various storage needs.
Offers 1 PCIe x4 expansion slot to add devices such as storage cards, network cards, or video cards to meet various application needs.
Provides 1 DP and 1 HD interface, supports high-resolution display output, suitable for multimedia applications and monitoring management.
Application scenarios:
Enterprise-class Network Attached Storage (NAS): High-capacity storage and RAID support, suitable as an enterprise data storage and backup solution with high security and reliability. High-speed network connectivity and high-capacity storage support concurrent multi-user access and file sharing.Data centers and servers: Compatible with Core i3/i5/i7/i9 processors, suitable as a high-performance computing node in the data center to handle complex computing tasks.Virtualization and Cloud Services: Supports virtualized environment, provides efficient operation of multiple virtual machines, suitable for deployment of cloud services.Industrial control system: High-performance processors and multi-network card configuration are suitable for industrial data acquisition and processing, providing high reliability and low latency control system.Media Server: Provides high-capacity storage and high-speed data transfer, suitable for streaming media server and high-definition content playback for home or enterprise.Video Editing and Storage: High-performance processors and large-capacity memory, ideal for video editing and high-quality video storage.Edge Computing: Provides localized data processing and storage as an edge computing node, reducing latency and bandwidth consumption.Product Specifications:
Model
8-BAY NAS Q670
Processor
LGA1700 Socket Intel 12th to 14th Gen Celeron/Pentium/Core i3/i5/i7/i9
BIOS
AMI EFI BIOS (UEFI boot only)
Memory
2*DDR5 SO-DIMM Memory slot, Up to 96GB 4800MT/s
Storage
2*M.2 2280(NVMe); 8*SATA 6.0Gb/s (Raid 0,1,5,10)
Ethernet Controller
4*Intel i226 2.5GbE (Compatible with 10/100/1000/2500Mbps)
Display Port
1*DP port; 1*HD port
Expansion slot
1*PCIe x4 Gen4
Other functions
Power-on boot; Scheduled boot; Wake-up on LAN; PXE boot; Watchdog
Power Supply
Flex 1U ATX 100-240V~,6A-3A~/60~50Hz Maximum Output Power 400W
Package Size
430*430*340 (mm)
Purchase Notes:
1. Duties and customs fees. Our products do not include customs duties and fees. If your purchase page includes sales tax, it means that the AliExpress platform in your region has prepaid sales tax.
2. The warranty period is 1 year. Due to the buyer's refusal to sign for receipt; unwillingness due to personal reasons; return due to man-made damage; the cost must be borne by the buyer. Due to the product itself, the seller promises to repair or refund free of charge.
3. The desired configuration is not found. You may need to perform some configuration, such as adding or removing memory and hard drives; adding other accessories. If the purchase option you need is not on the page, you can contact sales and we will do our best to ensure your purchase needs.
4. Manuals and Specifications. Manuals are available for most of the products we sell. If you need to obtain them, you can contact our sales staff or send an email to [email protected]. Once we receive your request, we will get it to you quickly. Of course, you can also visit our website at www.bkipc.com to learn more about the products and download the product materials yourself.
5. Fast shipping. We understand your shipping needs. That is why we offer AliExpress shipping; Commercial Express (UPS; DHL; FedEX) for you to choose from. Typically, most Commercial Express shipments can be shipped within 1 week and most AliExpress shipments can be shipped within 2 weeks. Some countries or regions may experience delays due to insufficient flights, slow customs clearance, and long transit times, so please be patient. If you need specific logistics information, please contact us and we will keep you updated on your shipment.
We know you are a careful person, the basic product information ends here. If you have any questions about the product, you can contact us directly or send an email to and we will get back to you as soon as possible.
