Descripción
Integrated chip graphics card/sound card/network card
Main chipset AMD B550
Chipset description Using AMD B550 chipset
Display chip integrated AMD Radeon display chip
Audio chip integrated Realtek ALC887 7.1 channel audio chip
NIC chip onboard Realtek GbE Gigabit NIC
Processor specifications
CPU type Third generation AMD Ryzen
CPU socket Socket AM4
Memory specifications
Memory type 4×DDR4 DIMM
Maximum memory capacity 128GB
Memory description Support dual-channel DDR4 4733(O.C.)/4600(O.C.)/4400(O.C.)/4000(O.C.)/3600(O.C.)/3333(O.C.)/3200/2933/2667/2400/2133MHz memory
Storage expansion
PCI-E standard PCI-E 4.0
PCI-E slot 1×PCI-E X16 graphics card slot, 1×PCI-E X1 slot
Storage interface 2×M.2 interface, 4×SATA III interface
I/O interface
USB interface based on CPU:
4×USB3.2 Gen1 interface (backplane)
Based on chipset:
2×USB3.2 Gen1 interface (built-in), 6×USB2.0/1.1 interface (4 backplanes, 2 built-in)
Video interface 1×HDMI interface, 1×DVI interface
Power connector One 8-pin, one 24-pin power connector
Other interfaces 1×COM interface, 1×PS/2 keyboard and mouse universal interface, 1×RJ45 network interface, 3×audio interface
Board type
Motherboard type Micro ATX type
Dimensions 24.4×24.4cm
Software management
BIOS performance 1 256 Mbit flash, using authorized AMI UEFI BIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
