Descripción
Processors
Intel Core i3-4005U, 2 cores, 4 threads, 1.70GHz
Intel Core i5-4200U, 2 cores, 4 threads, 1.60GHz, up to 2.60GHz
Intel Core i7-4500U, 2 cores, 4 threads, 1.80GHz, up to 3.0GHz
Intel Core i3-5005U, 2 cores, 4 threads, 2.0GHz
Intel Core i5-5200U, 2 cores, 4 threads, 2.20GHz, up to 2.70GHz
Intel Core i7-5500U, 2 cores, 4 threads, 2.4GHz, up to 3.0GHz
Intel Core i7-4600U, 2 cores, 4 threads, 2.10GHz, up to 3.30GHz
Memory Types
SODIMM DDR3L RAM 1333/1600MHz
Storage
Support 1x mSATA SSD ( defaulted install this type hard drive )
Support 1x 2.5 inch SATA HDD/SSD
Graphics
Integrated Graphics
Network Interfaces
2x GbE RJ45 Realtek 8111E, Support Wake on LAN
Expansion
1x Mini PCI-E slot for WiFi/Bluetooth module (half height size )
OS Support
Windows 7
Windows 8.1
Windows 10
Windows 10 ioT
Windows 10 Embedded
Linux/Ubuntu
USB Ports
4x USB3.0
Display Port
1x VGA, 1x HDMI
Serial Ports
2x RS232
i7-4600U / i5-5200U COM ports support adjust to RS232/RS485
Audio Ports
3.5mm combo audio jack 2-in-1
Construction
Fanless passive cooling
Case
Aluminum Case
Dimension
180x125x55mm
Netweight
1.30Kg
Operating
Temperature
-20℃ to +60℃
RH
5%~90% @30℃，Non-condensing
Power Adapter
Input AC100-240V, Output DC12V-5A/3A
Package List
1x Mini PC
1x AC Adapter
1x Power cord ( EU AU US UK type plug shipped according to buyer’s address )
1x SATA cables
1x User manual
1) Buyer need to add 3G/4G Modules to mini PC, please contact us.
2) Buyer requires COM ports that support RS-485, please buy " i5-5200U RS232/485" and "i7-4600U RS232/485" options.
