Ventilador de refrigeración DC 5v 12v 24V 5015 ventilador Turbo Radial 50x15MM accesorios de impresora 3D 50MM sin escobillas 5CM ventilador enfriador H2

Cooling Fan DC 5v 12v 24V 5015 Radial Turbo Blower 50x15MM 3D Printer Accessories 50MM Brushless 5CM Cooler Fan H2

5015 Brushless Turbo DC Fan 5V 12V 24V Cooler Blower Silent Oil-Containing Micro Centrifugal Fan For 3D Printer Accessories

Description

3D Printer Parts 5015 Blower Fan 5V 12V 24V Turbo cooling fan 5cm 50x50x15mm 5V/12V/24V Black Plastic Fans for Extruder

【Features】
1. Machine mute oil-containing micro centrifugal fan
2. Using a diameter of 5cm DC turbine
3. Centrifugal fan design
4. The product is simple and convenient to use
5. Conscience made of high-quality PBT material

【Specification】
Bearing: oil /Sleeve Bearing
Rated voltage: 5V 12V 24VDC
Operating voltage: 3.7V~7VDC
Starting voltage: 3.7VDC
Rated current: 0.20±0.05A
Rated power: 1W±10%
Rated speed:
5v 4000rpm/min±10%
12v 5000rpm/min±10%
24v 6000rpm/min±10%

Maximum air volume: 0.14m3/h
Maximum static pressure: 16.60pa or 0.30inch-H2O
Noise: 33.7dBA
Life expectancy: 30000hrs at 40℃
Operating temperature and humidity range: -10~+65℃ 15%~90%RH
Storage temperature, humidity range: -20~+85℃ 15%~90%RH
Product shell material: PBT material

【Notice】
1. Do not exceed the limit specified in this specification when using, otherwise we do not guarantee this product
2. The screw torque of the lock shell shall not exceed 4Kg

【Package list】
1pcs or 3pcs Oily micro centrifugal fan
