V770 PRO-C (USB Interface) / V770 PRO-A Portable Wearable Head Mounted Display 0.39-inch OLED for Safety Monitoring FPV
Description:
- Wearable head mounted displays are widely used in security monitoring: they are common in night vision inspections in mining and construction industries, and can be paired with night vision cameras and thermal imaging cameras.
Application:
- 800 x 600 active matrix color 0.39 inch OLED panel module uses single crystal silicon transistor
- The display module can be equivalent to 2 meters distance virtual 80 - inch screen
- VGA pixels of micro display chip, image as well as the light source system, high-performance optical engine, the drive control circuit
- FPV model aircraft display, easy to plug in both the user to carry and operate
- Monocular display suite, night vision, medical, information, infrared detection, power monitoring electronic suite viewfinder
- Metal case with internal fixing bracket, waterproof, dustproof and shockproof
- Equipped with 38MM eyepieces, custom hoods
- User-friendly straps are comfortable and convenient, while supporting up and down adjustment
- Head-mounted displays are widely used in safety monitoring: they are common in night vision inspections in the mining and construction industries. In addition, head-mounted displays can be combined with
night vision cameras and thermal imaging cameras.
- Industrial medical video shows: human and machine vision engineering research, aviation navigation, machine vision imaging, various testing equipment, dental diagnostic equipment, medical X-ray perspective, tunnel geological and marine exploration and utilization, scientific research institutes.
- Endoscope: it is basically connected to a large screen monitor in medical applications, and there is only one doctor who really needs to observe. As a consequence, the use of head-mounted display can protect the privacy of patients. Besides, you can release your hands,
and the display effect is clearer than that of ordinary display.
- Ultrasound: the application of ultrasound in today's market is low-resolution, small screen. In addition, ultrasound is more and more
widely used in our life and work. Analogy: large-scale farms need to observe and test the fertility of some animals, and large-scale farms
have supporting super waves. Super use is very disturbing for users and objects to use at night and outdoors. The display of the machine itself
will emit a strong light when working at night, which interferes with the resting object.
Specification:
- Display: 0.39 inch OLED
- Resolution: 800 x 600
- Screen Ratio: 4:3
- Color depth: 24bit input
- Viewing angle: 45°diagonal
- Video input: composite AV/CVBS
- Video signal: NTSC/PAL/SECAM automatic selection
- Working voltage: 3.7 - 5V
- Working current: 5mA
- Power consumption: 0.1W
- Display frame frequency: 120Hz (NTSC), 100Hz (PAL)
- An exit pupil distance: 20mm
- An exit pupil diameter: 1-2m
- Eyepiece: 16X optical
- Bright adjustment: yes
- Diopter adjustment: yes
- Dimension: 18 x 8 x 9cm
- Weight: 0.35kg
Package Included:
- 1 x Display
- 1 x Bind
- 1 x User Manual
