USB3.0 SDI 60FPS HD Video Capture Card HD to USB 3.0 2.0 Video Recording Box adapter Dongle Game Live Streaming Broadcast
Features:1.Connect multiple dongles to one machine2.Enable the up/down conversion of video resolution, frame rate and audio sampling rate3.Support brightness, contrast, hue, saturation, and other screen adjustment functions4.Nsendato HD video capture meets UVC standard, support YUV 4:2:2 (YUY2) or RGB 4:4:4 (RGB24) video output5.The Nsendato HD video capture meets UAC standard and 48KHz PCM stereo audio output6.The video processing engine can be updated via firmware without changing the hardware.7.Automatically detect and de-interlace signals8.Reliable and Stable: 64MB DDR2 Onboard memory, it can effectively conduct video frame buffer and USB transfer flow control to avoid interruption or error images when the USB transmission bandwidth is occupied.Pass through 7x24h continuous high load tests in high and low temperatures (0-50 degrees)9. Easy to Use: No need to install drivers in Windows, Linux, and OS X, real plug and play.Compatibility:1.Compatible with various USB 3.0 chipsets (Intel, Renesas, ASMedia, Fresco Logic), compatible with expended USB 3.0 via PCIe Gen1.1 x12.Compatible with USB 2.03.Compatible operating systems:For Windows (7, 8, 8.1),For Linux (kernel version 2.6.38 and above), For OS X (10.8 and above)4.Support APIs, such as Windows: For DirectShow, For DirectSound, For Linux: V4L2, ALSA, OS X: QuickTime5.Support software including For Windows Media Encoder (Windows), For Adobe Flash Media Live Encoder (Windows, OS X), For Real Producer Plus (Windows), For VLC (Windows, For OS X, Linux), For QuickTime Broadcaster (OS X), For QuickTime Player (OS X), For Wirecast (Windows, OS X) and etc.Excellent Video Processing:1.Support up to 1920x1200p60 (CVT-RB) Video Input2.Video output support up to 1920x1200p60 in YUY23.Video output support up to 1920x1200p60 in RGB244.The process of video and audio is done by the dongle and will not occupy CPU.Specifications:Host Interface:USB3.0 300-350MB/s throughput;USB2.0 40MB/s throughputInput Interface:HDMI-compatible interface/1 SDI interfaceHD Video Input:1080P/60HZ HD HD signal or SDI signalHD Audio Input:1 LPCM audio signalHD Input Formats:meets HD standard and supports 1080p/60Hz 8-bit, (RGB, YUV) or HD-SDI/3G-SDIOutput Formats:Up to 48KHz, 85db, 24-bitVideo Sampling Rate:HDMI-compatible--165MHzAudio and Video Capture:It meets the standards of UVC (USB video class) and UAC(USB audio class)Output Color Space:YUY2,RGB24Video ProcessingSwitch of Color Space:Hardware Color SwitchImage Scale:Hardware ScaleImage Adjustment:The image adjustment of brightness,contrast,hue,saturation OthersOS Support:supports the following operating systems (x86 and x64 versions):For Windows 7 Windows Server 2008 R2;For Linux (Kernel version 2.6.38 and above);For OS X (10.8 and above)Software Compatibility:For Windows Media Encoder (Windows);For Adobe Flash Media Live Encoder(Windows, OS X);For Real Producer Plus(Windows);For VLC (Windows, OS X, Linux);For QuickTime;Broadcaster (OS X);For QuickTime Player (OS X);For Wirecast (Windows, OS X), etc.Pacakge:1 x HD+SDI Capture Dongle1 x USB Cable1 x User Manual
