Descripción
Welcome to Yao Caixing Electronic store!
1. We are professional product and sale LED display2. We are provide low price and high quality3. Welcome to our factory for inspection in ChinaOur Advantage
1.CCC,CE&Rohs,ISO9000,FC,
2.Life span:more than 100000h
3.Excellent after-sales services with free repaire whole life
4.MOQ: 1pcs 500x500mm die-casting aluminum cabinet screen.
5.Our package type:wooden box or flight case(extra charge)
6.Prompt delivery: 7-12 work days
Specification
Module Parameter
Size
250mm(H)×250mm(H)
Module Resolution
42(H)×42(W)
Pitch
5.95mm
Density
28.224pixels/m²
LED Lamps
SMD1921
Driver IC
Universal chip(Customizable )
Module Refresh
3840hz
Mask
Pure Black mask-high contrast screen
Cabinet Parameter
Cabinet Resolution
84(H)×84(W)
Cabinet Size
500mm(H)×500mm(W)
Cabinet Weight
9.8kg
Driver Mode
Dynamic 1/16scan , constant current driving
Cabinet Power
≤200w
Cabinet Thickness
≤73mm+12mm
Electricity Parameter
Optical Ratings
Brightness Of White Balance
≥5500cd/m²
View Angle
140 degree ( horizontal) 140degree(vertical)
View Distance
5m-180m
Gray Scale
65536
Display Color
3-in-1 RGB
Brightness Adjustment
100 levels
Power Supply
Operation Power
AC100-240V 50-60HZ Switch-able
Maxim Power Consumption
800 w/m²
Average Power Consumption
400 w/m²
Control System
Correction Scale Level
16bits
Screen Refresh Frequency
1920Hz
Gamma Correction
-5.0—5.0
Support Input
HDMI,DVI,VGA,RJ45,USB,Serial Port
Control Distance
Ethernet cable 100m, optical fiber 5km
Support VGA Mode
800×600,1024×768,1280×1024,1600×1200,1920×1080
Color Temperature
5000-9300 adjustable
Brightness Correction
dot by dot, module by module, cabinet by cabinet
Reliability
Temperature
Storage:-35℃-+80℃ ;
Operation :-25℃-+45℃
Humidity
Storage:10-70% RH ;
Opeartinon:10--60% RH
Operating Life
≥100,000 hours
MTBF
≥10.000 hours
Continuous Working Time
≥48 hours
Protection Level
IP54
Out of Control Pixel Rate
0.03%
Product specifications are for reference only and subject to change without prior notice;
Please contact sales for details
At the same time, we can design according to customer requirements and production.
Pictures
MOQ:1 set 500x500mm aluminum cabinet screen accessories
1),4pcs P5.95 modules ,
2),1pcs 5v40a200w power supply,
3),3pcs avation power plugs
4),3pcs avation web lines
5),2pcs power lines ,
6),4pcs flat cables ,
7),4 feets
8),1pcs Novastar receiving card
9),1pcs 500x500mm die-casting aluminum cabinet
- Sample will package by foam and carton
- More orders will use woodens cases pack
- Flight case package also is available (extra charge)
Shipment
1. Check clearly order address .2. The images shown are not the actual item and are for your reference only. 3. We will choose to ship your item from our first available warehouse for fast delivery.
Certificate
Hope you love and choose us ,thanks for your surpport
We'll try to do better and better in the future.Have a nice day !!!Shenzhen Yao caixing Electronic Co.,LTD
