SIMCOM SIM8200EA‐M2 Módulo 5G Sub-6G M.2 Multibanda 5G-NR LTE-TDD LTE‐TDD Comandoes WCDMA Compatible Cat12 SIM7912G SIM7920G

SIM8200EA-M2

The SIM8200EA-M2 is the Multi-Band 5G NR/LTE-FDD/LTE-TDD/HSPA+ module which supports R15 5G NSA/SA up to 4Gbps data transfer.

It has strong extension capability with rich interfaces including UART,PCIe,USB3.1, GPIO etc. The module provides much flexibility and ease of integration for customer's application.

The SIM8200EA-M2 adopts M.2 form factor, TYPE 3052-S3-B. AT commands of SIM8200-M2 series are compatible with SIM7912G/SIM8300G-M2 series modules. This also minimizes the investments of customers, and enables a short time-to-market.

It is designed for applications that need high throughput data communication in a variety of radio propagation conditions. Due to the unique combination of performance, security and flexibility, this module is ideally suited for many applications.

Product Advantages

• Standard M.2 interface.

• High throughput data communication.

• AT commands of the SIM8200EA-M2 is compatible with SIM7912G/SIM8300G-M2 series modules
