Descripción
Features:
1. Compact Size: With dimensions of just 6.6cm x 3.8cm, this brushed PWM motor driver module is incredibly compact. Even with a 1cm thick heat sink attached, the total height remains at just 2.8cm, making it easy to integrate into various setups.
2. Versatile Voltage Support: This high power DC motor driver board supports a wide voltage range of 10-36V, providing versatility in usage. It offers undervoltage protection and can be independently powered up to a maximum of 50V, ensuring reliable performance in diverse applications.
3. High Load Capacity: Capable of sustaining a maximum continuous load current of 20A (with a simple heat sink attached), this PWM DC motor speed controller can handle demanding tasks. It can even withstand short-time peak currents of up to 110A, enabling efficient control of high-power motors.
4. Comprehensive Control Options: This brush motor driver controls module allows for three-wire speed control, bidirectional rotation, and brake functions. It supports full PWM control and can be easily operated using buttons for direction control. The PWM range spans from 0% to 100.0%, providing precise motor control.
5. Easy Integration with Microcontrollers: Seamlessly interface this brushed DC motor driver board with PLC systems and 3.3V/5V microcontroller IO ports. It features built-in level buffering capabilities, eliminating concerns about damaging the microcontroller IO pins. Enjoy hassle-free integration and reliable control functionality.
Specification:
Motor Type: DC Motor
Module Nature: H-Bridge Brush DC Motor Driver Module For 3-36V High Power DC Motors
Scope of Application: High-Power DC Motor Drive. Wide Input Voltage (11-36v) Requirements Of The Occasion. Such As Large Cars, Robots And Other Various Control.
Driving Voltage: DC 11-36V Input DC Voltage (Prohibited Input AC)
Output Current: Rated Continuous Output 24V 15A 360W Or Less Without Heat Sink, Maximum 36V 15A 450W
Output Power: Natural Cooling Rated 450W Measured At 36V 15A Power Supply
Operating Temperature: Industrial Grade (-40°C To +85°C) Full Load Temperature: 45°C
Weight: 293g
Product Features:
- Small size, only 6.6cm×3.8cm. After being attached to a 1cm thick layer for heat dissipation, the total height is 2.8cm
- It supports a voltage range of 10 to 36V, with under-voltage protection. The maximum independent power supply can reach up to 50V
- The maximum continuous load current is 20A(with a simple heat sink attached), and the short-term peak current is 110A
- It can control speed regulation, forward and reverse rotation, and braking in three lines
- It supports full PWM, allowing direct control of forward and reverse rotation using keys. The effective PWM range is 0% to 100.0%
- It can be directly matched with PLC and 3.3V 5V single-chip microcomputer IO ports to directly control the built-in interface level buffering function, eliminating the worry of damaging the single-chip microcomputer IO.
