Descripción
Motherboard chip
Integrated chip sound card/network card
Main chipset AMD 990FX
The chipset description adopts AMD 990FX Northbridge+SB950 Southbridge chipset
Display chip APU built-in display chip (requires APU support)
Audio chip integrated with Realtek ALC892 8-channel sound effect chip
Network card chip onboard Realtek RTL8111F gigabit network card
Processor specifications
CPU type Phenom II/Athlon II/Sempron 100/FX
CPU socket Socket AM3+
CPU description supports AMD 32nm processors
Memory specifications
Memory type 4xDDR3 DIMM
Maximum memory capacity 32GB
Memory Description: Supports dual channel DDR3 1866/1600/1600/1333/1066MHz memory
Storage Expansion
PCI-E Standard PCI-E 2.0
PCI-E slot 4 x PCI-E X16 graphics card slot, 1 x PCI-E X1 slot
PCI slot 1 x PCI slot
Storage interface 6 x SATA III interface
I/O interface
USB interface 12 x USB 2.0 interface (4 built-in+8 backplane), 6 x USB 3.0 interface (2 built-in+4 backplane)
One 8-pin power interface and one 24 pin power interface
Other interfaces: 1 x RJ45 network interface, 2 x eSATA interface, 1 x fiber optic interface, audio interface, 1 x PS/2 keyboard and mouse universal interface
Plate type
Motherboard type ATX board type
Dimensions 30.5 × 24.4cm
