Descripción
Our Advantage
1.CCC,CE&Rohs,ISO9001,FC,
2.Life span:more than 100000h
3.Excellent after-sales services with free repair whole life
4.MOQ: 1pcs
5.Prompt delivery: 14 working days after get deposit.
Spcification
Module Parameter
Module Resolution
32(H)×64(V)
Pitch
5mm
Density
40.000pixels/m²
LED Lamps
SMD2727
Driver IC
Normal chips
Size
160mm×320mm
Module Refresh
2560hz
Mask
Pure Black mask-high contrast screen
Cabinet Parameter
Cabinet Resolution
120(H)×120(W)
Cabinet Size
960mm(H)×960mm(W)
Cabinet Weight
35kg
Driver Mode
Dynamic 1/5scan , constant current driving
Cabinet Power
≤700w
Cabinet Thickness
≤135mm+5mm
Electricity Parameter
Optical Ratings
Brightness Of White Balance
≥6000cd/m²
View Angle
140 degree ( horizontal) 140degree(vertical)
View Distance
4m-100m
Gray Scale
65536
Display Color
3-in-1 RGB
Brightness Adjustment
100 levels
Power Supply
Operation Power
AC100-240V 50-60HZ Switch-able
Maxim Power Consumption
1000 w/m²
Average Power Consumption
500 w/m²
Control System
Correction Scale Level
16bits
Screen Refresh Frequency
1920Hz
Gamma Correction
-5.0—5.0
Support Input
HDMI,DVI,VGA,RJ45,USB,Serial Port
Control Distance
Ethernet cable 100m, optical fiber 5km
Support VGA Mode
800×600,1024×768,1280×1024,1600×1200,1920×1080
Color Temperature
5000-9300 adjustable
Brightness Correction
dot by dot, module by module, cabinet by cabinet
Reliability
Temperature
Storage:-35℃-+80℃ ; Operation :-25℃-+45℃
Humidity
Storage:10-70% RH ; Operation:10--60% RH
Operating Life
≥100,000 hours
MTBF
≥5000 hours
Continuous Working Time
≥48 hours
Protection Level
IP70
Out of Control Pixel Rate
≦0.03%
Attention!!!
product need at least 14 working days to produce ,pls extend the delivery time after you ordered
