Descripción
We choose the convenient express so that you can get the goods early
We can accord your size make the machine you wish
Specification
Module Parameter
Module Resolution
32(H)×64(V)
Pitch
5mm
Density
40.000 pixels/m²
LED Lamps
SMD1921
Driver IC
Universal chip
Size
160mm×320mm
Module Refresh
1920hz
Mask
Pure Black mask-high contrast screen
Cabinet Parameter
Cabinet Resolution
160(H)×96(W)
Cabinet Size
1.8m(H)×1.28m(W)
Cabinet Weight
80kg
Driver Mode
Dynamic 1/8 scan , constant current driving
Control System
HD-A30(4G+WIFI+RJ45 asynchronous control)
Cabinet Thickness
≤130mm+60mm
Electricity Parameter
Optical Ratings
Brightness Of White Balance
≥5500cd/m²
View Angle
140 degree ( horizontal)
140degree(vertical)
View Distance
4m-260m
Gray Scale
65536
Display Color
3-in-1 RGB
Brightness Adjustment
100 levels
Power Supply
Operation Power
AC100-240V 50-60HZ Switch-able
Maxim Power Consumption
2000 w
Average Power Consumption
1000w
Control System
Correction Scale Level
16bits
Screen Refresh Frequency
1920Hz
Gamma Correction
-5.0—5.0
Support Input
HDMI,DVI,VGA,RJ45,USB,Serial Port
Control Distance
Ethernet cable 100m, optical fiber 5km
Support VGA Mode
800×600,1024×768,1280×1024,1600×1200,1920×1080
Color Temperature
5000-9300 adjustable
Brightness Correction
dot by dot, module by module, cabinet by cabinet
Reliability
Temperature
Storage:-35℃-+80℃ ; Operation :-25℃-+65℃
Humidity
Storage:10-95% RH ; Operation:10--90% RH
Operating Life
≥100,000 hours
MTBF
≥5000 hours
Continue Working Time
≥48 hours
Protection Level
IP67
Out of Control Pixel Rate
≦0.03%
Pictures
Hope you love and choose us ,thanks for your surpport we'll try to do better and better in the future.Have a nice day !!!
Shenzhen Yao caixing Electronic Co.,LTD
