Descripción
motherboard chip
Integrated Chip Sound Card/Network Card
Main Chipset Intel Z170
Chipset Description Intel Z170 Chipset
Display chip CPU built-in display chip (requires CPU support)
Audio chip Integrated Realtek ALC1150 8-channel audio chip
Network card chip Onboard Intel I219V Gigabit network card
Processor Specifications
CPU type Sixth generation Core i7/i5/i3/Pentium/Celeron
CPU socket LGA 1151
CPU description Support Intel 14nm processor
memory specification
Memory type 4×DDR4 DIMM
Maximum memory capacity 64GB
Memory description Support dual-channel DDR4 3866+(OC)/3600(OC)/3200(OC)/2933(OC)/2800(OC)/2400(OC)/2133MHz memory
storage expansion
PCI-E standard PCI-E 3.0
PCI-E slot 2×PCI-E X16 graphics card slot, 2×PCI-E X1 slot
Storage interface 1×M.2 interface, 2×SATA Express interface, 8×SATA III interface
I/O interface
USB interface 1×USB3.1 Type-A interface, 1×USB3.1 Type-C interface, 7×USB3.0 interface (1 built-in + 6 backplane), 2×USB2.0 interface (built-in)
Video interface 1×DVI interface, 1×Display Port interface, 1×HDMI interface
Power interface One 8-pin, one 24-pin power interface
Other interfaces 1×RJ45 network interface, 1×optical fiber interface, audio interface, 1×TPM interface, 1×Thunderbolt lightning interface, 1×PS/2 keyboard and mouse universal interface, 1×COM interface
plate type
Motherboard form factor ATX form factor
Dimensions 30.5×24.4cm
