GY-33 TCS34725 Módulo de detección de sensor de reconocimiento de color alternativo TCS230 TCS3200

Overview

GY-33 is a low-cost color recognition sensor module.

3-5V operating voltage, small power consumption, small size, easy installation.

Its working principle is, the illumination light emitting LED, is irradiated to the measured

After the object, the return light detection filter after the RGB value ratio

The ratio of the RGB value recognized color.

This module, there are two ways to read data, i.e.,

Serial UART (TTL level) or IIC (2 lines).

Serial baud rates and 9600bps 115200bps, configurable,

Continuous, query output in two ways, can be powered down to save the settings.

Simple identification of seven colors, RGB values need not be calculated.

Can adapt to different working environment, connected to the microcontroller and computer.

Further modules may be separately provided a sensor device operating mode,

As a simple sensor module, MCU is not involved in data processing.

Provide arduino, 51, stm32 SCM communication procedures,

It does not provide schematics and source code inside the microcontroller.

Product selling point:

1. Using high-quality materials, the quality is guaranteed

2. Built-in MCU to calculate color

3.IIC, serial communication format

4. Adjustable LED brightness

5.can be used as a simple simple TCS34725 module.

6. internal MCU TCS34725 can read data, the MCU directly output RGB calculation, internal white balance process, support serial / IIC read.

Provided: microcontroller 51, the microcontroller Arduino, stm32 microcontroller, (IIC / serial) communications program to read the data.

Parameter:

Measurement range: RGB0-255

Response frequency: 10 H7

Working voltage: 3-5v

Working current: 15mA

Working temperature: -20°~85°

Storage temperature: -40°-- 125°

Size: 24.3mm × 26.7mm

Sensor chip: TCS34725
