3610RL-04W-B56 9025 12V 0.38A 9cm Ventilador de refrigeración PWM para servidor, equipos industriales, fuentes de alimentación, electrónica de alto rendimiento
7,49 € 9,13 €
Con la garantía de
Selección del modelo
Enviado desde
comprobando cupones disponibles...
Some placeholder content for the collapse component. This panel is hidden by default but revealed when the user activates the relevant trigger.
Brand: NMB-MAT
model: 3610RL-04W-B56 PN:453473-001size: 92*92*25mm
voltage: DC12V
current: 0.38A
power: 4.56W
rotational speed: 1000-3500 RPM
air volume: 20.3-60.4CFM
noise: 20-47.6 dBA
wiring: the 4p interface of the main board supports speed measurement and PWM temperature control.
Bearing: high precision ball bearing
frame for fan: Injection Molding once, PBT + 30% glass fiber + VO grade flame retardant
fan blade: Injection Molding once, PBT + 30% glass fiber + VO grade flame retardant
fan rotation direction: from the direction of the fan blade, it is counterclockwise running
temperature:-20 degrees Celsius to +70 degrees Celsius storage temperature:-40 degrees Celsius to +80 degrees Celsius
bearing: high precision double ball bearing
power supply range: positive and negative 15% of rated power supply
insulation electronic resistance: greater than 500 megoo
withstand voltage: sink leakage current 0.5mA 500V/1 minute
working life: 100000 hours when the ambient temperature is 25 degrees
Comprar 3610RL-04W-B56 9025 12V 0.38A 9cm Ventilador de refrigeración PWM para servidor, equipos industriales, fuentes de alimentación, electrónica de alto rendimiento
