100pcs/lot Crystal Oscillator 20MHz 20 MHz 20M Hz Mini Passive Resonator Quartz HC-49S
Parameter:
Hold Type: HC-49US
Normal Freq：3.2~90MHz
Freq. Tolerance: ±20PPM（-20~70 Celsius）
Freq. Tolerance: ±20PPM（-20~70 Celsius）
Operating Temp: -20~70 Celsius
Oscillate Mode: FUNDMENTAL
Shunt Capacitance: 7pf Max
Drive Level: 50UW
Load Capacitance: 12PF
Aging in a year: 3PPM
Rr: 120ohm Max
Ins. Resistance: 500ohm Min/DC 100V
Mechanical and environmental performance:1) Free fall (impact)It fell freely from a height of 75cm to a hardwood board of 30mm thickness and dropped three times, that is threquiring the technical specifications.2) Sealing: Immerse the resonator in alcohol and pressurize it at 5Kg/cm2 for 5 minutes. Remove the insulation resistance 500 ohm (DC100V) from the test pin to the pedestal.3) Solderability: From the end of the pin to the bottom of 2~2.5mm, place it in a solder bath of 235 degrees Celsius ± 5 degrees Celsius for 2 ± 0.5 seconds, and the tin solder surface is 90%. Meet the technical specifications.4) Vibration resistance: The vibration frequency is 10~55Hz and the amplitude is 1.5mm. After each vibration in the X, Y, and Z directions for 2 hours, the test is performed. It meets the technical specifications and there is no mechanical damage.Crystal Oscillator 20MHz 20 MHz 20M Hz Mini Passive Resonator Quartz HC-49S
