Módulo de conector CP2102/CH9102 USB 2,0 a UART TTL, convertidor de serie STC, reemplazo FT232, CH340, PL2303, CP2102, MICRO USB

RED

Common sense (very important):

TXD: Sending end, generally expressed as its own sending end, normal communication must be connected to the RXD of another device.

RXD: Receiver, generally expressed as its own receiver, normal communication must be connected to the TXD of another device. During normal communication, its own TXD is always connected to the device's RXD!

Self-receiving and self-transmitting: During normal communication, the RXD is connected to the TXD of other devices, so if you want to receive the data sent by yourself, as the name suggests, that is, you will receive the data sent by yourself, that is, your own TXD is directly connected to the RXD to test its own transmission and reception. Whether it is normal or not is a quick and simple test method. When there is a problem, first do the test to determine whether the product is faulty. Also called loopback test.

Level logic:

ITL level: Usually the data is expressed in binary, it is stipulated that +5V is equivalent to logic "1", 0V is equivalent to logic "0", called TTL signal system, it is positive logic

S232 level: use -12V to -3V, equivalent to logic "0", +3V to +12V logic level, equivalent to logic "1", is negative logic

Product Description:

1. The main chip is CP2102. After installing the driver, a virtual serial port is generated.

2. USB power supply, the lead-out interface includes 3.3V ( 40mA), 5V, GND, TX, RX, the signal pin level is 3.3V, positive logic

3. On-board status indicator, transceiver indicator, the status indicator will be always on after the driver is installed correctly, the transceiver indicator will flash when communicating, the higher the baud rate, the lower the brightness

4. Support baud rate from 300bps to 1Mbps

5. Communication format support: 1) 5, 6, 7, 8 data bits; 2 support 1, 1.5, 2 stop bits; 3) odd, even, mark, space, none check

6. Support operating system: windows vista/xp/server 2003/200, Mac OS-x/OS-9, Linux7, the USB head is male, which can be directly connected to the computer USB port

8. SMD components are produced by SMT process, with stable quality

BLACK

Common sense (very important):

TXD: Sending end, generally expressed as its own sending end, normal communication must be connected to the RXD of another device. RXD: Receiver, generally expressed as its own receiver, normal communication must be connected to the TXD of another device. During normal communication, its own TXD is always connected to the device's RXD!

Self-receiving and self-transmitting: During normal communication, the RXD is connected to the TXD of other devices, so if you want to receive the data sent by yourself, as the name suggests, that is, you will receive the data sent by yourself, that is, your own TXD is directly connected to the RXD to test its own transmission and reception. Whether it is normal or not is the fastest and simplest test method. When there is a problem, the first test is done to determine whether the product is faulty. Also called loopback testing.

Level logic:

TTL level: Usually the data is expressed in binary, and it is stipulated that +5V is equivalent to logic "1", and OV is equivalent to logic "0", which is called TTL signal system, which is positive logic

RS232 level: use -12V to -3V, equivalent to logic "0", +3V to +12V logic level, equivalent to logic "1", is negative logic

Product Description:

1. The main chip is CP2102. After installing the driver, a virtual serial port is generated.

2. USB power supply, with 3.3V and 5V power output, leading out all useful pins

3. With self-recovery fuse. In case of accidental short circuit, it can effectively protect your downloader and computer USB port

4. The onboard status indicator, transceiver indicator, the status indicator will be always on after the driver is installed correctly, and the transceiver indicator is in communication.

5. Support baud rate from 300bps to 1Mbps

6. Communication format support: 1) 5, 6, 7, 8 data bits; 2) 1, 1.5, 2 stop bits; 3) odd, even, mark, space, n

one check

7. Supported operating systems: windows 8.1/7/vista/xp/98, Mac OS-X/OS-9, Linux8, the USB head is male, which can be directly connected to the computer USB port

9. SMD components are produced by SMT process, with stable quality 10. Volume without USB head: W15.5*L26.5 (mm) 11. Weight: 4g

12. With reset signal output, it can be directly sent to Promini and other I/o motherboards (409) CP2102 module _USB to TTLUSB to serial port UART flash board STC downloader (409) CP2102 module USB to TTL USB to serial port UART flash board STC download Onboard program!
