AMPCOM-cuchilla de fibra óptica, herramientas FTTH, cortador de cables de alta precisión, cuerpo totalmente metálico, 12 hojas de superficie con bolsa, WAM-60S

Product Description

1. Precise cleaving: provides a cleave with a cutting angle of less than 0.5 for optimal fiber preparation for fusion splicing

Product Parameter

Applicable fibers:Silica optical fiber
Bare fiber diameter :125μm
Coating diameter:250-900μm
Cleaving angle:0.4-0.8 degrees with single fiber
Blade life:48000 times(100*16*3)

AMPCOM All-metal High Precision Fiber Optic Cleaver

High quality slide rail automatic tool return

Package Contents

1x AMPCOM Fiber Cleaver,
1x User Manual,
1x Black bag
2 x Allen Wrench

User Manuals

Question:Is it possible to get instructions in english?

Answer:If u are using 125 micron, 250-900 micron. Use ur choice of fiber strippers to expose the cladding and core. Cable is now ready for prep to cleave.
This cleaver is a three step process
- step one push actuator to the loaded position that located in the front of the cleaver
- step two open cleaver and lift fiber holder and place fiber in the appropriate holder on either 250um or 900 um. (It should fit snug and not be able to move).
-step three close lid and this will actuate the cleaver blade. ( at this time fiber will be cut and ready to splice).
-finally you can open the cleaver and support and remove fiber for splice, quick crimp, etc

Question:Is this cleaver okay for 9/125 single mode fiber?

Answer:Yes, there are measurements on the tool. For SM, line the fiber up on the 13.

Question:Could this work for fast connect connectors. i need to precision cleave single mode fiber at 10.5 mm for insertion into a fast connect.

Answer: Of course can

Question:Can this cleaver be used with fusion splicer?

Answer:Yes, it can
