Description
MATERIAL
Pin header: Brass, Tin plated
Housing:PA66, UL94V-0
ELECTRICAL
Rated voltage: 300V
Rated current: 15A
Contact resistance: 20mΩ
Insulation resistance:5000MΩ/DC1000V
Withstand voltage: AC2000V/1Min
MECHANICAL
Temperature range:-40℃~+105℃
SPECIFICATION
Pitch:5.08mm
Poles:2P/3P/4P/5P/6P/7P/8P
