Description
The Main Parameters:1. Standard certification: FCC / CE / TELEC2. Wireless standard: 802.11 b / g / n3. Frequency range: 2.4GHz-2.5GHz (2400M-2483.5M)4. Data interface: UART / HSPI / I2C / I2S / IR Remote Contorl / GPIO / PWM5. Operating voltage: 3.0 ~ 3.6v (Suggest 3.3v)6. Working current: average 80mA7. Operating temperature: - 40 degrees to 125 degrees8. Storage temperature: room temperature9. Package size: 16mm * 24mm * 3mm10. External interface: N / A11. Wireless network mode: station / softAP / SoftAP + station12. Security mechanisms: WPA / WPA213. Encryption type: WEP / TKIP / AES14. Upgrade firmware: local serial port burn, cloud upgrade, host download burn15. Software development: support customer custom server, provide SDK to customer secondary development16. Network protocols: IPV4, TCP / UDP / HTTP / FTP17. User Configuration: AT + instruction set, cloud server, Android / IOS APPItem Size:
Interface Definition:
1.RST: Reset the module2.ADC: A / D conversion result, input voltage range 0 ~ 1V, value range: 0 ~ 10243.EN: Chip enable, high active4.IO16: GPIO16, can do deep sleep wake-up when receiving RST pin5. IO14: GPIO14, HSPI_CLK6. IO12: GPIO12, HSPI_MISO7. IO13: GPIO13, HSPI_MOSI, UARTO_CTS8.VCC: 3.3V power supply9. GND: GND10. IO15: GPIO1611.IO2: GPIO2,UART1_TXD12.IO0: GPIO013.IO4: GPIO414.IO5: GPIO515.RXD:UARTO_RXD,GPIO316.tXD:UARTO_tXD,GPIO1
Interface Definition:1.RST: Reset the module2.ADC: A / D conversion result, input voltage range 0 ~ 1V, value range: 0 ~ 10243.EN: Chip enable, high active4.IO16: GPIO16, can do deep sleep wake-up when receiving RST pin5. IO14: GPIO14, HSPI_CLK6. IO12: GPIO12, HSPI_MISO7. IO13: GPIO13, HSPI_MOSI, UARTO_CTS8.VCC: 3.3V power supply9. GND: GND10. IO15: GPIO1611.IO2: GPIO2,UART1_TXD12.IO0: GPIO013.IO4: GPIO414.IO5: GPIO515.RXD:UARTO_RXD,GPIO316.tXD:UARTO_tXD,GPIO1
